COMPRESSOR
|
|
OIL
SEPARATOR - RECEIVER TANK |
| Type |
Rotary
Twin Screw, Single Stage |
Type |
Vertical-cylindrical,
full-welded |
| Free Air
Delivery |
185
cfm, 5.0m3/min |
Dia. of Shell |
10.4 in /
263 mm |
| Working
Pressure |
100 psi, 7
bar |
Length of Shell |
27.6 in /
700 mm |
| Max.
Working Pressure |
120 psi,
8.4 bar |
Capacity |
1.24 cft /
0.035m3 |
| Lubrication System |
Forced
Lubrication by Compressed Air |
Air Outlet |
3/4" x
2 |
| Driving System |
Direct
Coupling with Engine |
. |
| Oil Cooling System |
Air Cooled |
COOLANT
AND LUBRICANT CAPACITY |
| Compressor Oil Filter |
Paper
Cartridge Type |
Cooling Water |
2.6 gal /
10 L |
| Air Cleaner |
Dry Paper
Element Type |
Fuel (Diesel) |
21 gal / 80
L |
| . |
Engine Oil |
1.6 gal / 6
L |
| DIESEL
ENGINE |
Compressor
Oil |
3.7
gal / 14 L |
| Model |
ISUZU C240 |
. |
| Type |
Vertical
In-line, 4-Cycle, Water Cooled, Swirl-Chamber Type |
WEIGHT |
| No. of Cylinder |
4 |
Dry Weight |
2205 lbs /
1000 kgs |
| Cyl. Bore X Stroke |
4-3.4 X 4.0
in / 4.86 X 102 mm |
Operating Weight |
2425 lbs /
1100 kgs |
| Total Displacement |
145 cu. in
/ 2369 cc |
. |
| Rated Output |
50 hp /
37.3 kW |
SOUND
LEVEL |
| Max. Torque |
98.3
ft/lbs/2000 rpm / 13.6 kgf-m/2000 rpm |
At 7 meters ISO 4872 |
71 dBA
|
| Injection Pump |
Bosch Type |
. |
| Governor |
Centrifugal,
Mechanical, All-speed |
OPERATING
PARAMETERS |
| Lubrication System |
Forced
Circulation by Trochoid Pump |
Max. Altitude above sea |
4921 ft /
1500 m |
| Oil Filter |
Full-flow
Type |
Max. Ambient Temperature |
113°F / 45°C |
| Cooling System |
Forced
Circulation by Volute Pump |
Min. Ambient Temperature |
-4°F / -20°C |
| Air Cleaner |
Dry Element
Type |
Max. Operating Incline |
15° |
| Starter |
DC 12 V,
2.0 kW |
|
| Alternator |
AC 12 V, 35
A |
| Battery |
12 V |
| Cooling Fan |
Pusher Type
17 in / 430 mm |
| Speed |
1300/3000
rpm |
| NOTE:
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE. |
